Neutrik FiberFOX 2CH foxBRID NO2M4RW-FX
- Buy 10 for £169.11 each and save 16%
Features & Benefits
- Very rugged plug face
- Very compact design - fits into industrial modular connectors
- Insensitive to electromagnetic influences
- Easy patching with common LC patch Cords
- No splicer, no expertise required for Installation
- Extremely service-friendly
The FIBERFOX 2CH foxBRID is an expanded beam multimode hermaphroditic connector module and is suited for a vast array of industrial applications, including automation, robotics and railway. The innovative design ensures its ability for deployment in the toughest environments where constant performance and total reliability are critical. The module is designed according to the MIL-DTL-83526 standard and fits to other FIBERFOX solutions.
Benefiting from the expanded beam technology and the precision optical alignment the system creates high immunity against dust, mud, liquids and other contaminations. The FIBERFOX foxBRID module converts a standardized LC Patch cable into an expanded beam solution. It acts as a “feed-through” and fits into industrial standard shells.
For example:
- Han-Modular® Harting
- RockStar® ModuPlug Weidmüller
- Etc.
Technical Information
Product
| Title | FIBERFOX 2CH foxBRID |
| Product code | NO2M4RW-FX |
| Gender | Hermaphroditic |
Mechanical
| Chassis Shape | Rectangular |
| Lifetime | > 10`000 mating cycles |
| Locking device | Screwed & Dependent to Modular locking device |
| Vibration | IEC 61300-2-1 & 61373 |
| Shock | IEC 61373 |
Material
| Insert | Steel |
| Shell | Aluminium |
| Shell plating | Hard anodize |
Environmental
| Flammability | UL 94 V-0 |
| Protection class | IP 20 |
| Compatibility | MIL-DTL-83526 |
| Temperature range | -40° C to +85° C |
Optical
| Insertion loss | Typ. 0.9 db per connector / max. 1.45 db per connector |
| Optical connector | EBC |
| Optical wiring ISO / IEC 11801 | ISO / IEC 11801 |
| Downloads Data | https://directcablesystems.com/media/downloads_data/fiberfox_foxbrid_2ch_27423000_01.dwg https://directcablesystems.com/media/downloads_data/fiberfox_foxbrid_2ch_27423000_z_01.pdf https://directcablesystems.com/media/downloads_data/neutrik_insertion_loss_calculator.xlsm https://directcablesystems.com/media/downloads_data/neutrik-fiberfox_industrial_solutions-nf34_v01_202207.pdf https://directcablesystems.com/media/downloads_data/bda_626_v1-fiberfox_cleaning_and_inspection.pdf |
|---|---|
| Change Image | Yes |
| Neutrik Code | NO2M4RW-FX |
| Brand | Neutrik |
| Datasheet | https://directcablesystems.com/media/downloads_data/fiberfox-2ch-foxbrid.pdf |
| Size | 2 Channel |
| Price on Application | No |
| Non-Priority | No |
